Grand Stream Switch Smart L2 8 Port Gigabit, PoE \ GWN7701P

The Grand stream GWN7701P Smart Layer 2 Managed Switch rises to this challenge,

offering a seamless combination of power, speed, and smart management in a compact design.

Overview

The GWN7701P is an 8-port Gigabit Ethernet switch equipped with Power over Ethernet (PoE) capabilities,

specifically designed to deliver reliable connectivity and centralized management for small to medium-sized networks.

With Layer 2 switching features and smart capabilities, it ensures optimal traffic handling, enhanced security, and simplified administration.

Key Features

• 8 x Gigabit Ethernet Ports: Each port supports speeds up to 1000 Mbps, ensuring ultra-fast data transfer and minimal latency.

• PoE+ Support (802.3af/at): With a total power budget of up to 65W, the switch can power a wide range of PoE-enabled devices such as IP cameras, VoIP phones, and wireless access points.

• Smart Layer 2 Management: Includes VLAN support, QoS (Quality of Service), IGMP snooping, port mirroring, and loop detection, allowing efficient traffic segmentation and prioritization.

• Web-Based Management Interface: Intuitive GUI that simplifies configuration, monitoring, and maintenance tasks.

• Fanless Design: Ensures silent operation, making it suitable for office or quiet environments.

• Durable Metal Housing: Offers long-term durability and protection in both desktop and wall-mounted installations.

Performance and Reliability

The GWN7701P is built for stability and performance. With non-blocking switching capacity, it ensures data flows smoothly even under heavy load. Features like storm control and loop prevention protect the network from broadcast storms and network failures, keeping uptime high.

Ideal Use Cases

• Small and Medium Enterprises (SMEs)

• Surveillance Systems (CCTV with PoE cameras)

• VoIP Deployments

• Educational Institutions

• Retail and Hospitality

Why Choose Grand stream GWN7701P?

Grand stream has long been recognized for delivering cost-effective, high-quality networking and communication solutions. The GWN7701P continues this legacy by offering robust Layer 2 management features at a competitive price point, without compromising on performance or security.

Conclusion

For businesses seeking a reliable, smart-managed PoE switch that’s easy to deploy and manage,

the Grandstream GWN7701P is a strong contender. Whether powering VoIP phones or securing a video surveillance system,

this switch delivers the speed, control, and reliability modern networks demand.

• Casing: Metal

• 8× 10/100/1000Mbps RJ45 Ports, AUTO Negotiation, AUTO MDI/MDIX

• Network Media 1000Base-T/100Base-TX/10Base-T, Half/Full-Duplex

• 1~4 Ports 802.3 af/at compliant

• Up to 30W on Each Port

• Max. PoE Power Budget 60W

• Overload to cut off the lowest-priority port

• Priority: Port 4 to Port 1

• Mac Address Table 8K

• Switching Capacity 16Gbps

• Jumbo Frame 9KB

• Desktop/Wall-Mounted

• Mac Address Auto-Learning & Auto-Aging

• IEEE 802.3x Flow Control, 802.1p/DSCP QoS

• Unlink clear FDB Feature

• IGMP Fast-Leave, IGMP Snoop, Route Port Autolearn, Query Refresh Member Port

• Standards & Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at

• LED Indicators: Per port Link/Activity Green, Per device Power Green

• External 48-53.5VDC/1.22A Power Adapter included

• Max. Power Consumption by Base System 3W (excluding PoE output power)

• Compliance FCC, CE, RCM, IC, UKCA

• Operating Temperature 0 to 40°C

• Storage Temperature -40 to 60°C

• Operating Humidity 10% to 90% Non-condensing

• Storage Humidity 10% to 90% Non-condensing

• Unit Dimensions (L x W x H) 190 x 100 x 28mm

• Package Dimensions (L x W x H) 230 x 210 x 51mm

• Unit Weight 0.44Kg

• Entire Package Weight 0.92Kg

• 3 Year Warranty
